| TNC Termination Load, 2W DC- 18 GHz Precision |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Stainless Steel, Passivated Power: 2W VSWR: < 1.35@18 GHz, Typ. <1.25 |
| TNC Termination Load, 2W DC- 18 GHz Precision |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Stainless Steel, Passivated Power: 2W VSWR: < 1.35@18 GHz, Typ. <1.25 |
| TNC Termination Load, 2W DC- 12 GHz Economic |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Brass, Ni plated Power: 2W VSWR: < 1.35@12 GHz, Typ. <1.25 |
| TNC Termination Load, 2W DC- 12 GHz Economic |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Brass, Ni plated Power: 2W VSWR: < 1.35@12 GHz, Typ. <1.25 |
| TNC Termination Load, 2W DC- 18 GHz Economic |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Brass, Ni plated Power: 2W VSWR: < 1.35@12 GHz, Typ. <1.25 |
| TNC Termination Load, 5W DC- 18 GHz Precision |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Connector, Stainless Steel, Passivated, Heat sink Anodized Aluminum Power: 5W VSWR: < 1.35@18 GHz, Typ. <1.25 |
| TNC Termination Load, 5W DC- 18 GHz Precision |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Connector, Stainless Steel, Passivated, Heat sink Anodized Aluminum Power: 5W VSWR: < 1.35@18 GHz, Typ. <1.25 |
| TNC Termination Load, 10 W DC- 18 GHz Precision |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Connector, Stainless Steel, Passivated, Heat sink Anodized Aluminum Power: 10 W VSWR: < 1.35@18 GHz, Typ. <1.25 |
| TNC Termination Load, 10 W DC- 18 GHz Precision |
 |
 |
Conductor: Beryllium Copper, Gold plated Insulator: PTFE Body: Connector, Stainless Steel, Passivated, Heat sink Anodized Aluminum Power: 10 W VSWR: < 1.35@18 GHz, Typ. <1.25 |
